This is an excerpt from a raw recording of evoked currents exported from
Clampfit as an .abf file. It was then converted into a regular dataframe using the import_ABF_file()
function. To reduce the package installation size, I kept only three columns from the original file. This dataset is used to demonstrate the
plot_spontaneous_current_trace() function.
Format
An Axon Binary Format (.abf) file with 43061 observations of 3 variables.
- episode
A factor representing the sweep, such as "epi1".
- current
Numeric value representing current amplitude in pA.
- time_sec
Time in seconds.
Examples
plot_spontaneous_current_trace(
data = sample_abf_file,
plot_colour = "#6600cc",
plot_category = 2,
plot_treatment = "Control",
state = "Baseline",
plot_episode = "epi1",
trace_annotation = "Baseline",
geom_text_colour = "#6600cc"
)
